SPECIFICATION
| Mold | PLJ-250 | PLJ-320 |
|---|---|---|
| Outer Diameter(mm) | 320 | 400 |
| Inner Diameter(mm) | 250 | 320 |
| Weight（kg） | 735 | 1000 |
| Total Length(mm) | 2520 | 2520 |
| Splitting Speed（s） | 20 | 20 |
| Drilling Diameter(mm) | 130 | 130 |
Mold: PLJ-250
Outer Diameter(mm): 320
Inner Diameter(mm): 250
Weight（kg）: 735
Total Length(mm) :2520
Splitting Speed（s） :20
Drilling Diameter(mm): 130
PROJECT
Loading the next set of gallery items...
PRINCIPLES
Based on the brittleness of rock and concrete inside, the wedge principle is designed to release great splitting force in the narrowest hole,the split can be done in a matter of seconds
First, put the hydraulic splitter into the 130 mm hole, making sure that all the top mechanical blocks are put in.
Then start the reversing valve, start to feed oil, the piston shaft starts to move, push the middle mechanical block to move downward, and the edge quickly expands, and split lines will appear on the rock surface.
